The Role of Extraocular Muscle Monitoring in Brainstem Surgeries

Aisha Khan & Faisal R. Jahangiri

Intraoperative neurophysiological monitoring (IONM) is valuable in various surgical procedures. In cases where the brainstem is the target, monitoring the extraocular muscles can assist in reducing the risk of injury and preserving neural function. Delicate cranial nerves are frequently encountered during cranial base surgeries, and their lack of epineurium makes them highly vulnerable to damage. IONM provides continuous feedback on the integrity of cranial nerves, enabling surgeons to operate on offending lesions while minimizing the risk of injury. The selection of neuromonitoring techniques used depends on the location of the lesion being operated on [1].

Before performing a surgical procedure that involves the brainstem, it's critical to identify any potential risks to the nervous system. Brainstem-based surgeries can potentially harm the function of extraocular muscles. However, using IONM during the procedure can help mitigate the risk of damage. On the other hand, if IONM is not utilized, there is an increased risk of injuring an extraocular muscle, which could result in diplopia. Left untreated, diplopia can cause a patient to experience monocular vision and harm their peripheral and stereoscopic visual fields, significantly reducing their quality of life. Therefore, it's essential to preserve the normal function of extraocular muscles by using IONM.

During endoscopic endonasal skull base surgery, the extraocular muscles prove to be a valuable monitoring tool, as three distinct nerves innervate them: the oculomotor nerve (CN III), the trochlear nerve (CN IV), and the abducens nerve (CN VI) [3]. The specific innervations correspond to the individual muscles that make up the extraocular group. Electromyography (EMG) is the most commonly utilized neuromonitoring technique in this type of surgery.

Electromyography (EMG) can be classified into two distinct types: free running or spontaneous EMG (sEMG) and triggered EMG (tEMG). Free running EMG provides continuous recording of motor unit potentials in muscle fibers and has a higher level of specificity and negative predictive value when it comes to postoperative cranial nerve deficits [4]. This gives surgeons greater confidence when operating on cranial nerves. On the other hand, triggered EMG activity is observed when an electrical stimulus is applied to the cranial nerve, recording compound muscle action potentials from muscle fibers [4].

Skull base tumors frequently invade surrounding structures, like the cavernous sinus, and can cause damage to the extraocular nerves responsible for eye movement [5]. These tumors are typically quite large when detected, and the surrounding anatomy may already be compromised. Therefore, surgeons can use intraoperative monitoring of extraocular nerves to identify precise locations and avoid inadvertent injury. The preservation of extraocular monitor nerves during skull base tumor surgeries has been thoroughly researched, and some studies have reported using EMG to help with the monitoring process. It is worth noting, however, that EMG requires the placement of electrodes by a skilled and trained professional. While not as widely researched as other methods, Electrooculography (EOG) is a simple and effective way to track extraocular muscle movement [6]. Researchers are exploring using EOG monitoring in skull base surgeries, particularly in preventing extraocular motor nerve function issues during tumor removal [7-10]. EOG measures the electrical signals generated by eye movements, which can indicate abnormal oculomotor function [4,5]. These signals are easy to track and provide insight into eye movement abnormalities.

Disclaimer:

These extraocular electrodes must be placed by experienced neurophysiologists or under their direct supervision to prevent injury.

Sources:

1. Iaconetta G., de Notaris M., Cavallo L. M., et al. The oculomotor nerve: microanatomical and endoscopic study. Neurosurgery. 2010;66(3):593–601. doi: 10.1227/01.neu.0000365422. 36441.c8.

2. Kawamata T, Ishii N, Amano K, Namioka T, Hori T, Okada Y. A novel, simple real-time electro oculographic monitoring system during transsphenoidal surgeries to prevent postoperative extraocular motor nerve dysfunction. Neurosurg Rev. 2013; 36:371–6.

3. San-Juan D., Barges-Coll J., Gómez Amador J. L., et al. Intraoperative monitoring of the abducens nerve in extended endonasal endoscopic approach: a pilot study technical report. Journal of Electromyography and Kinesiology. 2014;24(4):558–564. doi: 10.1016/j.jelekin.2014.04.001.

4. Raftopoulos C Abu Series B Duprez T Docquier M A Guérit J M Microsurgical results with large vestibular schwannomas with preservation of facial and cochlear nerve function as the primary aim Acta Neurochir (Wien) 2005734697–706., discussion 706.

5. Ingster-Moati I, Bui Quoc E, Pless M, Djomby R, Orssaud C, Guichard JP, et al. Ocular motility and Wilson's disease: A study on 34 patients. J Neurol Neurosurg Psychiatry. 2007; 78:1199–201.

6. Marmor MF, Zrenner E. Standard for clinical electro-oculography. International Society for Clinical Electrophysiology of Vision. Arch Ophthalmol. 1993; 111:601–4.

7. Møller AR, editor. Intraoperative Neurophysiological Monitoring. 3rd ed. Totowa, New Jersey: Humana Press; 2011. Practical aspects of monitoring cranial motor nerves; pp. 235–60.

8. Sekiya T, Hatayama T, Iwabuchi T, Maeda S. Intraoperative recordings of evoked extraocular muscle activities to monitor ocular motor nerve function. Neurosurgery. 1993; 32:227–35.

9. Sekhar L. N., Moller A. R. Operative management of tumors involving the cavernous sinus. Journal of Neurosurgery. 1986;64(6):879–889. doi: 10.3171/jns.1986.64.6.0879.

10. Melek NB, Blanco S, Garcia H. Electro-oculography of smooth pursuit and optokinetic nystagmus eye movements in type I Duane's retraction syndrome. Binocul Vis Strabismus Q. 2006; 21:37–44.
